| YS-ZB-5040B | |||
| Semi Automatic Shrink Wrapper Machine | |||
| L-sealer with shrink tunnel "combo"system | |||
| Techical Parameters | YS-ZB-5040B | ||
| Power supply | 3P+N 230V/380V | ||
| Maximum power required | 6.5KW | ||
| Overall machine dimensions | W775 x L2405mm x H1500 | ||
| Working plate height(on stand) | 920mm | ||
| Tunnel entrance dimensions | 450 x230mm | ||
| Tunnel length | 700mm | ||
| Machine weight | 270kg | ||
| Sealing area | W500mm x L 400mm | ||
| Maximum product height | 160mm | ||
| Impulse sealing system | top blade | ||
| Maximum roll width | 600mm | ||
| Compressed air consumption | 1NI/cycle | ||
| Compressed air pressure | 6bar | ||
| Output | 15pcs/min | ||
| Electrical configuration | Intermediate relay:"Schneider"/"Omron" | Contactor:"Scheider" | Button switch:"Scheider" |
| Temperature controller:"MEIWA" | Time relay:"MEIWA" | Motor:"MEIWA" | |
| Pneumatic element:"Airtac" | |||
*Notes: Technical data subject to variations without prior notice Output depends on the operator and the type of the package
