YS-ZB-5AY
Shrink Wrapper
L type full automatic
 Wrapper machine(5AY) Shrink Tunnel (RS-5)
Power supply220V,50Hz,16A,3KW 380V  50Hz  32A  7kw
Packing speed
20-25 package/min
Convey speed
18m/min
Cutting film and sealing of time<1s/cycle
Machine dimensions L1800×W850×H1600mm L1600×W850×H1500mm
Entrance size of Tunnel   550mm*250mm
Working plate height
780mm
Machine weight 520kg 150kg
Sealing knife material;
Stainless steel,spray Teflon;
Sealing temperature;
180-250℃

Packing objects:

Packing objects

  • Minimum sealing dimensions;(A×B×C)90mm×90mm×10mm
  • Maximum sealing dimensions;(A×B×C)550mm×450mm×150mm
  • Maximum product;L500mm×W400mm×H120mm;W+H≤450
  • Biggest annotations;B+C must not more than 500mm
  • Largest size cannot be used  A×B×C to do the packing

Film parameters:

  • Type;POF film
  • Film thickness;0.015-0.019㎜
  • Film lateral contraction ratio;60%
  • Film vertical contraction ratio;60%

Electrical configuration:

  • Contactor;France“Schneider”
  • Button switch;France“Schneider”
  • Temperature controller;Japan“Omron”or Tain wan“Gongbao”
  • Intermediate relay;France“Schneider”
  • Pneumatic element;Tain wan“Air TAC”
  • Motor;“Gold Vader”
  • Control; PLC control
