AB2000 Labeling Machine
Safety cautions to operate labeling machine:
＊While operation, the operating staff stands right ahead the machine 10cm from the machine (freely operating the labeling object and control panel is appropriate).
＊Please prepare grounding wire to prevent accidents.
＊Please confirm the power supply for the machine. Don't plug wrong power supply. This machine adopts one way 220V power.
＊Do not extrude hands into the machine cover to prevent nipping accident or electric shock.
＊Do not flushing the machine by water. If the workplace is humid, the operating staff should not operate on barefoot.
＊Don't change the parts of the machine freely.
＊If the machine is not used, please roll back the label into the label spool to prevent dirty and humidity.
＊It is only technicians who can repair the electric equipment.
＊If do not use the machine, please pull out power plug.
＊Main parts should frequently be lubricated by oil.
|AB2000 Labeling Machine|
|It can label for round bottles(which can be conveyed vertically) or on side surface of other packings|
|Power supply||IP 220V 50HZ750W|
|Air pressure||2-5 kg/cm 2|
|Applicable container height||50-300mm(3:1 ratio for height and diameter)|
|Applicable container diameter||￠25-100mm(>￠100mm need to customize)|
|Applicable label||adhesive sticker(transparent and special stickers need to customize)|
|Applicable label range||L(1 5-250)mmxH(≤120)mm|
|Space between labels||≥3mm|
|Label scroll||土 1 mm(except container error)|
|Table height||950 mm|
